A 3D card rotation reveal — where a card turns in on its Y-axis, settles flat, then turns back out as the reader keeps scrolling — is normally built with a scroll-triggered animation library like GSAP ScrollTrigger, computing a rotation value from the card's position relative to the viewport on every scroll frame. This snippet builds the identical effect using nothing but a per-element native CSS view timeline: the browser itself supplies the "how far through the viewport is this card" value, and a single @keyframes block maps that value to a Y-axis rotation.

A view timeline per card

Each .vcr-card declares its own view-timeline-name: --card-in and view-timeline-axis: block. Because every card uses the same custom-ident name, each card still gets an entirely independent timeline instance scoped to itself — card two's own transit through the viewport has nothing to do with card one's. That per-element timeline then drives an animation-timeline: --card-in reference on the same element's @keyframes vcr-turn animation.

Shaping entry AND exit with a comma-separated animation-range

Unlike a simple fade that only needs an entry range, this rotation needs two distinct windows: the card turning in as it enters, and turning back out as it exits. animation-range: entry 0% cover 45%, exit 55% exit 100% supplies both: the first range covers the entry phase (0% of entry to 45% covered), and the second covers the exit phase (55% through exit to fully exited). The keyframes themselves are written to match — from/30%/45%,55%/to — so the card is flat and fully opaque only in the very middle of its visible window, and turned away with reduced opacity at both edges.

Why rotateY and not a simple slide

A Y-axis rotation reads as physically dimensional in a way translateY or opacity fades do not — combined with perspective on the stage container and translateZ pulling the card slightly back during rotation, the card appears to be a physical object tumbling into and out of the page's plane rather than a flat layer sliding. backface-visibility: hidden prevents a distracting mirror-flash of the card's back face during the steepest part of the rotation.

Comparing to a per-element fade-in

View Timeline Image Reveal uses the same per-element view-timeline-name + animation-range pattern for a simpler clip-path reveal that only needs an entry range. This snippet demonstrates the natural next step: layering a second animation-range for the exit phase so the effect is symmetric on the way out, not just the way in.

Browser support

Chromium-based browsers (Chrome, Edge, Opera, Brave) support animation-timeline: view() today. Firefox and Safari support is still landing, so an @supports not (animation-timeline: view()) block resets every card to a flat, fully visible, non-rotated state rather than leaving cards stuck mid-turn or invisible.

Customizing it

Tune the entry 0% cover 45% and exit 55% exit 100% percentages to make the turn faster or slower relative to the card's total transit, swap rotateY for rotateX for a top-down tumble, or change view-timeline-axis to inline for a horizontally scrolling card row instead. Pair it with a Feature Cards layout or a Bento Grid for a scroll-paced feature story.

Build with AI

Build, Understand, Optimize, and Extend It With AI

You don't have to work through the dual animation-range math by hand. Paste this snippet's HTML, CSS, and JS into an AI coding assistant like Claude and ask it to explain exactly how the comma-separated animation-range: entry 0% cover 45%, exit 55% exit 100% maps onto the from/30%/45%,55%/to keyframe percentages in @keyframes vcr-turn, and why backface-visibility: hidden matters during the steepest part of the rotation. The same assistant is useful for extending the effect: ask it to alternate the rotation direction between cards (some turning in from the left, others from the right), add a subtle drop-shadow animation that intensifies as the card reaches its flat resting position, or convert the vertical stack into a horizontal scroll-snap row using view-timeline-axis: inline. Treat the code less like a finished artifact and more like a starting point for a conversation.

Prompt to recreate it

Copy this into your AI assistant of choice to build the effect from scratch, or as a jumping-off point for your own variant:

text

Build a vertical stack of cards that rotate in on their Y-axis as they enter the viewport, settle flat, then rotate back out as they exit — using only native CSS scroll-driven animations with per-element view timelines (animation-timeline: view() via view-timeline-name and view-timeline-axis). No JavaScript, no scroll event listeners, no animation library.

Requirements:
- Several card elements, each containing a heading and a short description, laid out vertically with generous spacing between them.
- Every card must declare its own view-timeline-name and view-timeline-axis: block, then reference that timeline via animation-timeline on a keyframe animation applied to the same element.
- Use a comma-separated animation-range with two ranges — one covering the card's entry into the viewport, one covering its exit — so a single keyframe animation can shape both the turn-in and the turn-out symmetrically.
- The keyframes must animate transform using rotateY() combined with perspective() and a translateZ() pullback, plus opacity, so the card reads as a physically dimensional object tumbling into and out of the page rather than a flat sliding layer. Set backface-visibility: hidden on the card face to avoid a mirrored flash mid-rotation.
- Wrap the whole effect in @supports not (animation-timeline: view()) so unsupported browsers show every card flat, fully visible, and untransformed instead of stuck mid-rotation.
- Keep any JavaScript limited to a CSS.supports('animation-timeline: view()') feature check for a console message — it must not drive or trigger the rotation itself.

Want to tighten it up first? Run this prompt through the AI Prompt Studio to score it across 8 quality dimensions, catch anti-patterns, and tune the wording for Claude, ChatGPT, or Gemini before you paste it in.

Step by step

How to Use

1
Paste the HTML, CSS, and JSAn intro, a four-card stack, and an outro render — no library needed.
2
Scroll down slowlyEach card rotates in on its Y-axis, settles flat, then rotates back out as it exits.
3
Scroll back upThe rotation reverses correctly because the animation is bound to a live view timeline.
4
Adjust animation-rangeWiden or narrow the entry/exit percentages to make the turn faster or slower.
5
Swap rotation axisChange rotateY to rotateX in @keyframes vcr-turn for a top-down tumble instead.
6
Export in your formatClick "HTML" for a standalone file, "JSX" for a React component, or "Tailwind" for a React + Tailwind version.

Real-world uses

Common Use Cases

Feature or product showcase sections

A CSS-only alternative entrance for a Feature Cards grid told one card at a time down the page.

Portfolio and case study pages

Give project cards a physical, dimensional entrance without any scroll library dependency.

Learn animation-range with two ranges

Study how a comma-separated animation-range shapes distinct entry and exit windows on one timeline.

Marketing landing page storytelling

Pace card reveals against scroll for a more memorable pitch than a static grid.

Replace a GSAP ScrollTrigger rotation

Removes the need for a scroll-linked rotation library for this specific per-card effect.

Related: View Timeline Image Reveal

See the View Timeline Image Reveal for the simpler entry-only version of this per-element view-timeline pattern.

Got questions?

Frequently Asked Questions

Each element that declares view-timeline-name creates its own independent timeline instance scoped to itself, even if multiple elements use the identical custom-ident name. The name is only used so the element's own animation-timeline property can reference it — it is not a shared, page-wide timeline the way scroll(root) is.

A single animation-range can list multiple ranges separated by commas, and each keyframe percentage in the associated @keyframes rule is then mapped proportionally across however many ranges are supplied. Here entry 0% cover 45% covers the first half of playback (the card entering) and exit 55% exit 100% covers the second half (the card exiting), letting one animation shape two distinct windows.

A Y-axis rotation combined with a perspective on the containing stage reads as a physically dimensional tumble rather than a flat opacity change, which draws more attention and feels more crafted for a hero-level feature showcase — at the cost of being a slightly heavier visual effect than a plain fade.

Yes. Because the animation is bound to a live view timeline rather than triggered once by an observer, scrolling a card back down out of view and then back up replays the exact same keyframe range in the corresponding direction with no manual reset needed.

The @supports not (animation-timeline: view()) block removes the animation and resets transform to none, so cards render flat and fully visible immediately in Firefox and Safari rather than being stuck mid-rotation or invisible.

Yes. Switch view-timeline-axis from block to inline and lay the cards out in a horizontally scrolling row (for example with scroll-snap) — each card's timeline will then track its transit across the horizontal viewport instead of the vertical one.
